01

Knife length for Dimension Clipper

mm

1,350

02

Working veneer width

max.  mm

1,270

03

Veneer thickness

mm

1.2 - 4.0

04

Feeding speed

max. m/min

28

05

Number of glue threads

rows

5

06

In-feed conveyor

 kw

2.2

07

Dimension clipper

 kw

1.5

08

Cooling fan

 kw

0.75

09

Water circulation pump

 kw

0.15

10

Heater for glue melting for edge and yarn application

 kw

6.3

                                                           Estimated consumption and other date

11

Total power required

~ kva

7

12

Air consumption

~liter/min.(at0,6mpа)

60

13

Total gross weight

~  kg

2,800

14

Shipping measurement

30(M3)
